    YC1893D Professional Stationary Meter Test System

    Ask Lasest Price
    Brand Name : GENY
    Model Number : YC1893D
    Certification : ISO, CE
    Price : negotiate rates
    Payment Terms : T/T,L/C,D/P,T/T
    Supply Ability : 5 sets / 1 months
    Delivery Time : 6~8weeks
    • Product Details
    • Company Profile

    YC1893D Professional Stationary Meter Test System

    YC1893D Professional Stationary Meter Test System


    Features and functions:


    • Parallel communication port for smart meter testing via RS232
    • Rack terminals for calibration and verification
    • Calibration/pulsing test for EDMI 3-phase meters
    • Accuracy testing for reference standard meters
    • Pre-warming function
    • Accuracy tests compliant with IEC standards
    • Creeping and starting current tests
    • Error repeatability test
    • Dial test
    • Influence tests (voltage, frequency, reverse phase sequence, voltage unbalance)
    • Harmonic and sub-harmonic analysis per IEC standards (IEC 62052-11 / 62053-21/22/23)
    • Odd harmonic analysis


    Customized features:


    - Individual/combined calibration (voltage, current, power).
    - 24+24 positions; 24 active; relay switch for toggling.
    - CT/WC range: 1(6)A, 1(10)A, 5(20)A, 5(100)A, 5(120)A.
    - Gating/pulse method.
    - DLMS (Mk10M), EDMI Command Line (Mk10E).


    Primary Competitive Advantages:


    1. High quality product
    2. Over 18 months long warranty
    3. High accuracy class: 0.05/0.02
    4. Can be customized of Three Phase Electric Energy Meter Test bench
    5. Extremely high power stability
    6. Neutral current test(optional)
    7. Timing error test
    8. Influence test of voltage, frequency, and harmonic
    9. Installing RS232, Ethernet communication port in each meter position.
    10. Tilt impact test (optional)


    Specification:


    Technical spec.

    YC1893D-ICT-6

    YC1893D-ICT-12

    YC1893D-ICT-24

    YC1893D-ICT-48

    Number of meter positions equipped ICT

    6

    12

    24

    48

    Accuracy class of ICT

    0.05 / 0.01

    Accuracy

    0.05

    Power Source

    YCS-103-250

    YCS-103-600

    YCS-103-1200

    YCS-103-2500

    Standard Meter

    SZ03A-K6 / SZ03A-K8 (customized)

    Scanning Head

    YCG-S Series

    Voltage


    Test voltage output(Phase-Neutral)

    3x(24V~288V)(or customized)

    Power of the voltage output

    Max. 3x100VA

    Max. 3x250VA

    Max.

    3x500VA

    Max.

    3x1000VA

    Resolution

    Better than 0.01% of full scale value of range

    Setting accuracy

    Better than 0.05% at the final range value

    Stability

    Better than 0.005% /h (integration time 150s)

    Load regulation from 0~max. load

    Better than 0.01%

    Distortion factor

    Better than 0.3% for linear resistance load

    Harmonic

    2nd~21st free programmable

    Current


    Test current output

    3x(1mA~100A)

    Power of the current output

    Max. 3x150VA

    Max. 3x350VA

    Max. 3x750VA

    Max. 3x1500VA

    Resolution

    Better than 0.01% of full scale value of range

    Setting accuracy

    Better than 0.05% at the final range value

    Stability

    Better than 0.005% /h (integration time 150s)

    Load regulation from 0~max. load

    Better than 0.01%

    Distortion factor

    Better than 0.3% for linear resistance load

    Harmonic

    2nd~21st free programmable

    Phase angle


    Range

    0~360⁰

    Resolution

    0.01⁰

    Setting accuracy

    0.1⁰

    Frequency


    Range

    45Hz~65Hz

    Resolution

    0.01Hz

    Error display


    Type of error display

    Red LED

    Resolution of error displays

    8 digitals

    Other


    Voltage supply

    3x220/380V±10%(or customized)

    50/60Hz ±2Hz

    Ambient temperature

    -10°C~+40°C

    Relative humidity

    35%~85%
